Show off your skills and solve real design problems
Think of any tool you always wanted to have but never found because nobody has made it yet. We want you to design it! Add the newly developed tool as a challenge entry with detailed description and user manual and get an oppurtunity to have your custom made tool 3D printed.
The tool can be useful in many different cases as well as custom made for very specific use in photography, electronics, aerospace, etc.
The main criteria is that it has to be 3D printed from the following material:
http://www.shapeways.com/materials/white_strong_flexible
If you feel comfortable the material properties are enough in purposes of tool performance you are ready to go.
We would also recommend you to upload the model to shapeways.com to check if the model is 3D printable.
Read more about the criteria under the requirements.
Thank you to xristos, Andrew Stephens, M. Janis Lavoie, Mohammad Ali, parampmd, Ricardo Luiz Teixeira and Arifin Sutur for the pictures.
Entry can be assembled maximum of 10 parts in total as long as it fits to 100x100x100mm cube
Model can be done in any CAD software as long as STL file for 3D print is provided
Model must be 3D printable
Entry needs to include user manual
Entry must be new in GrabCAD
All the jury members need to have access to private entries. Pick people to share access with on the right side of model view.
All the private entries will be made public after the end of competition.
You can submit several designs
Only models uploaded through this challenge page will participate in the competition
The competition is open to everyone, team entries are welcome
3D printed model from shapeways.com
GrabCAD T-Shirt
The winning tool will be chosen by GrabCAD engineers.
