Commel Socket Design Challenge

We want you to find a unique design for Commel's extension socket casings while keeping costs low!

Most sockets look boring, conservative, and haven't changed much over the past few decades. People use power cords every day, but that doesn't mean they have to look ordinary!

Your new design should be worthy of the spotlight, not something to hide away from view. We want customers to be able to pick out your design for Commel in stores because nothing looks quite like it!

You should only design the external casing, no need for internal parts. However, the technical structure of the socket must remain the same and the external design cannot impede its function.

Since the main goal of the Commel product line is to offer a low price for its customers, you should be aware of the final cost of your socket and use materials and designs that are inexpensive to build.

Requirements

  • Only external design is required for standard Europlug.

  • Maximum dimensions:
    Lenght: 300 mm
    Width: 45 mm
    Height: 45 mm
    Weight: ~0.245 kg

  • Material is Polypropylene (PP).

  • Please build your design with 6 socket places.

    -----------------------------------------------

    Since Commel has many socket types, your design should be adjustable to arrangements of 3, 5, or 6 socket places. Note: dimensions are not a top priority because a creative outer design is the main goal and designs can be adjusted at a later time.

  • You must include IGES or STEP files and at least one rendering. Native CAD formats are optional but encouraged.

  • Include your estimated final cost in your project description. A bill of materials (BOM) is encouraged, but not required.

Rules

  • The competition is open to everyone. Multiple entries are acceptable. Team entries are welcome - prize will be transferred to team leader.

  • Tag your entry with “eurosocket” when uploading to GrabCAD. If you submit through the "Submit entry" button, this should be added automatically. Only entries with valid tag will participate.

  • The winning designs becomes the intellectual property (IP) of the Challenge sponsor.

  • Only entries uploaded to GrabCAD through the "Submit entry" button on this Challenge page will be considered an entry.

  • By entering this competition, you 1. Warrant that the work is your original work. 2. To the best of your knowledge, it is not, and has not been in production or otherwise previously published or exhibited. 3. Neither the work nor its use infringes the intellectual property rights (whether a patent, utility model, functional design right, aesthetic design right, trade mark, copyright or any other intellectual property right) of any other person.

    -----------------------------------------------

    If you think an entry may infringe on existing copyrighted materials, please email challenges@grabcad.com.

  • Applicants are not entitled to any compensation or reimbursement for any costs. The applicant’s participation shall not constitute employment, assignment or offer of employment or assignment.

  • Winning designs will be chosen based on the rules and requirements. This Challenge starts on July 22, 2013 and ends on August 21, 2013 (11:59pm UTC). Winners will be announced by September 21, 2013.

  • All cash prizes awarded through Paypal. Void where prohibited.

  • The sum of the Awards is the total gross amount of the reward. The awarded participant is solely liable for the payment of all taxes, duties and other similar measures if imposed on the reward pursuant to the legislation of the country of his/her residence, domicile, citizenship, workplace, or any other criterion of similar nature.

  • We will release the finalists before the final announcement to give the Community an opportunity to "vote" for their favorites in the comments. The jury will take these into consideration when picking the final winner. This new addition is based on feedback from you!

Prizes

1st Place Winner

$500 cash for best design + GrabCAD tshirt and mug

2nd - 5th Place Winners

GrabCAD tshirt and mug

About the jury?

The jury is comprised of experts from Commel and GrabCAD.

About Commel

Commel has provided cable reels, mobile power stations, extension sockets, extension cables, and connection cables to its customers for over 20 years. Their products are intended for the consumer market, DIY stores, industry of electronic devices and home appliances, professional workers in handicrafts, construction industry, shipbuilding, etc.
