Mechanical Design

Created by Ramazan ÇELİKBAŞ on 9 April, 2021

78

discussions

5453

members
All discussions

Hi everyone, I need help with drawing in SOLIDWORKS. It’s about a new base that rotates. A tiltable drive unit is mounted on the X-axis and can measure surfaces in a range of ±45°. Can someone help me with this?

Savio Sylyester
Savio Sylyester
Mar 18

A lapping type stage that allows for fine movements after rough positioning and coarse 360° rotation. you can design a mechanical stopper to stop and limit 45deg



chris
chris
Mar 18

your request is not clear. it says that you need help with a drawing. but you haven't described the problem, or exactly what you need. Please clarify.


abdullah yousafzai
abdullah yousafzai
May 10

Which type of help do you want clarify it
