tutorial 6 ( ansys workbench ) / ( cutting tools simulation

By Armin Yousefi Kanani on 30 Jan 15:08 17 answers 11 comments

ansys workbench

after doing this tutorial do this one
https://grabcad.com/questions/ansys-tutorial-7-to-determine-the-best-angles-for-cutting-tools-cutting-tools-simulation

my other tutorial for ansys
https://grabcad.com/questions/ansys-tutorial-3
https://grabcad.com/questions/ansys-tutorial-2
https://grabcad.com/questions/ansys-tutorial-1
https://grabcad.com/questions/tutorial-5-ansys

<h1> Please read this before doing tutorial </h1>

As i mentioned in the first of tutorial, input data is not correct. Because my purpose was to show you how to run simulation step by step, not getting correct answer. I should have spent more time to solve simulation with real figure which I did not have that time unfortunately.
My suggestion is to solve it in small area with real figure for example, analyze model after cutting 5 mm of workpieces otherwise you need to spend a lot of time to solve it.

Regards
Armin

Last update : 22/02/2016

Added images

Square Square

17 answers

  • Armin Yousefi Kanani
    Armin Yousefi Kanani almost 4 years ago

    <h5>just be aware of that the question input as if ( speed , time , dimension ) is not real it mean you can't use it as academic project . I just wanted to show you the processing of cutting tools simulation therefore you need to change input data to make it real project. For instance you can not find cutting tools with 200 m/s so the real figure for speed is around 5 m/s </h5>.

    for real input data you can use
    cutting tools simulation

    Answered with a tutorial: https://grabcad.com/tutorials/tutorial-6-ansys-workbench-cutting-tools-simulation

  • Abhinav
    Abhinav over 3 years ago

    Thank you sir.Excellent tutorial.Please upload the pdf copy of the same if possible.

  • kaustubh kulkarni
    kaustubh kulkarni 11 months ago

    I have tried this but it shows some error, please send me ansys file or detailed steps .

  • iker srinu
    iker srinu over 3 years ago

    how to do step 3 which is important step to do remaining steps

  • saran sundar
    saran sundar over 2 years ago

    can i get tutorial like this for serpentine heat exchanger analysis

  • siline  Dina
    siline Dina almost 2 years ago

    thank you very much for this excellent Tutorial, I learned with you Ansys, I have a question for you, what is the expression that have issued in the results defined by the user in the party solution. Best regards

  • Mahros Darsin
    Mahros Darsin almost 2 years ago

    Thank for your helpful tutorial. It leads me to further improvement to my own project.

  • khalid saifullah
    khalid saifullah almost 2 years ago

    speed is 200 m/s this is confusing...
    No cutting tool has that speed..
    by this speed is the simulation is ok??
    plz help by answer..
    thank you

  • ADITYA RAJ SHARMA
    ADITYA RAJ SHARMA over 1 year ago

    Thanks for the tutorial
    Can you provide any links to simulation of turning operation on cylindrical steel rod in ANSYS ?

  • vikalp gupta
    vikalp gupta over 1 year ago

    How to analyse heat generated due to friction . On cutting tool without using apdl

  • Huy Quoc
    Huy Quoc about 1 year ago

    Thanks for your tutorial.
    How to find out cutting forces on the tool (X, Y, Z component)?

  • kaustubh kulkarni
    kaustubh kulkarni 11 months ago

    While doing analysis, give details of analysis setting please
